DH Robotics – RGI-100-30
DH Robotics – RGI-100-30
excl. VAT
Couldn't load pickup availability
Intelligent electric parallel gripper with rotation and 30 mm stroke up to 100 N gripping force.
Description
The DH-Robotics RGI-100-30 is a precise parallel gripper with integrated intelligence. Thanks to position and force control, it is ideal for handling delicate workpieces or for applications requiring variable gripping force.
The compact design, easy control via common interfaces and high repeatability make the gripper the ideal choice for automation tasks in assembly, testing and laboratory environments.
specification
| feature | Value |
|---|---|
| Max. payload | 0.5–1.0 kg (recommended) |
| Weight | 1.5 kg |
| Max. gripping force | 100 N |
| Hub | 30 mm |
| Protection class | IP40 |
| communication | RS485 / Modbus, Digital I/O |
| Connections | n.a. |
| Operating temperature | 0–40 °C |
| Power supply | 24 V DC ±10% |
| Robot flange | ISO 9409-1 compliant |
Scope of delivery
- Gripper DH-Robotics RGI-100-30
- Quick guide / documentation
- Communication cable/adapter depending on the selected interface (variant dependent)
This item is available in various configurations. The price shown refers to a sample configuration. Please contact us before ordering so we can work together to find the optimal configuration for your needs.
Made-to-order item , delivery time approx. 2–4 weeks.
All information about the product and technical data is provided without guarantee.
